Prime DX51D Grade Galvanized Steel Coil with Z61-Z80 Zinc Coating and Cold Rolled Base for Superior Corrosion Resistance

Name: Prime DX51D Grade Galvanized Steel Coil with Z61-Z80 Zinc Coating and Cold Rolled Base for Superior Corrosion Resistance
Brand: Wuxi Sylaith Special Steel Co., Ltd.
SKU: Carbon Steel
Price: 20.00 USD
Availability: InStock

Brand Name:	SLAST
Model Number:	Carbon Steel
MOQ:	1 Ton
Price:	Negotiable
Delivery Time:	7-15 days
Payment Terms:	30% T/T Advance + 70% T/T Balance

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

MTC

Product Name:

Galvanized Steel Coil (Hot Dipped)

Standard:

ASTM / AISI / JIS / EN

Base Material:

Cold Rolled Steel

Thickness:

0.12 Mm - 0.20 Mm

Zinc Coating:

Z61 - Z80 (30-275 G/m² Available)

Hardness:

Mid Hard

Spangle Type:

Regular Spangle (Big / Medium / Small / Zero Available)

Surface:

Zinc Coated, Non-oiled

Skin Pass:

Yes

MOQ:

1 Ton, We Can Accept Sample Order

Payment Term:

30% T/T Advance + 70% T/T Balance

Packaging Details:

Standard export sea-worthy packing or as customers required

Supply Ability:

1000+tons/month

Highlight:

DX51D Grade Galvanized Steel Coil

Z61-Z80 Zinc Coating Galvanized Coil

Cold Rolled Base Hot Dipped GI Coil

Product Description

Attribute	Detail
Product Name	Galvanized Steel Coil (Hot Dipped)
Grade	DX51D (SGCC / G450 / G550 / S550GD equivalent)
Standard	ASTM / AISI / JIS / EN
Base Material	Cold Rolled Steel
Thickness	0.12 mm - 0.20 mm
Zinc Coating	Z61 - Z80 (30-275 g/m² available)
Hardness	Mid Hard
Spangle Type	Regular Spangle (Big / Medium / Small / Zero available)
Surface	Zinc Coated, Non-oiled
Skin Pass	Yes
Processing Service	Welding, Punching, Cutting, Bending, Decoiling

Product Overview

Galvanized Steel Coils are carbon steel sheets coated with a layer of zinc through a hot-dipping process to provide superior corrosion resistance. Manufactured by Wuxi Sylaith Special Steel Co., Ltd, these coils combine the strength of cold-rolled steel with the durability of zinc protection, making them a preferred choice for a wide range of industrial and construction applications.

Our Prime Hot Dipped Galvanized Steel Coils are produced from a cold-rolled steel base and coated with a uniform zinc layer (Z61-Z80). The material undergoes strict quality control to ensure consistent mechanical properties, surface finish, and coating adhesion.

Key Advantages

Superior Corrosion Resistance: Zinc coating protects against rust and extends product lifespan
Excellent Formability: Cold-rolled base allows for easy bending, punching, and cutting
Consistent Quality: Possessing MCT certification and meeting standards such as ASTM, EN, and JIS
Versatile Applications: Suitable for roofing, pipe making, containers, and general fabrication
Flexible Options: Regular spangle finish, mid-hard hardness, and customizable packaging

Applications

The versatility of SLAST Galvanized Steel Coils makes them suitable for numerous industries:

Pipe Making: Ideal base material for manufacturing welded pipes and tubes
Roofing & Construction: Perfect for corrugated roofing sheets, wall panels, and building cladding
Container Manufacturing: Used for shipping containers, storage tanks, and industrial containers
General Fabrication: Suitable for making fences, small tools, machine parts, and household appliances
Cutting Sheets: Can be slit and cut into sheets for various industrial applications

Manufacturing Process

Hot Dip Galvanized Steel Coil is produced through a precise metallurgical process:

Base Material Preparation: High-quality cold-rolled steel coils (thickness 0.12-0.20mm) are used as the substrate
Surface Cleaning: The steel strip is degreased, pickled, and fluxed to remove impurities and prepare the surface for coating
Hot Dip Coating: The cleaned strip passes through a bath of molten zinc at approximately 450°C-460°C, creating a metallurgical bond
Cooling & Finishing: After coating, the strip is cooled, leveled, and undergoes skin pass rolling to improve surface finish
Inspection & Coiling: The finished product is inspected for coating weight, surface quality, and mechanical properties

This process ensures excellent zinc adhesion, uniform coating thickness, and long-lasting corrosion protection.

Frequently Asked Questions

Q1: What is the difference between DX51D and other grades like SGCC or Q235?

DX51D is a European standard (EN 10346) grade for hot-dip galvanized steel, designed for general forming and bending applications. SGCC is the Japanese standard (JIS G3302) equivalent, while Q235 is a Chinese carbon steel grade. All are suitable for similar applications, but chemical composition and mechanical properties may vary slightly. We can supply equivalents based on your required standard (ASTM, JIS, EN).

Q2: What does "Z61-Z80" zinc coating mean?

"Z" stands for Zinc, and the number indicates the coating weight in grams per square meter (total both sides). Z61-Z80 means the coil has a zinc coating of 61-80 g/m². Higher coating weights (up to Z275) offer better corrosion resistance. We can customize based on your project requirements.

Q3: Can you provide samples before bulk order?

Yes, samples are provided and available upon request. We welcome trial orders to test our quality before committing to larger volumes.

Q4: What is the difference between "oiled" and "non-oiled" surface?

Non-oiled surface means the coil is shipped without an anti-rust oil coating. This is suitable for applications requiring immediate painting or processing. Oiled surface has a thin protective oil layer to prevent white rust during storage and transport. We offer both options based on your needs.

Q5: What is "skin pass" and why is it important?

Skin pass (or temper rolling) is a light cold rolling step performed after galvanizing. It slightly reduces thickness, improves surface finish, eliminates yield point elongation (preventing Luders lines during forming), and ensures better flatness. All JUYE coils undergo skin pass for superior quality.

Q6: What payment terms do you accept?

We accept T/T (30% deposit + 70% balance before shipment). Other terms can be negotiated for long-term partnerships.

Q7: What is the delivery time?

Standard delivery time is 7-15 days after order confirmation, depending on quantity and customization requirements.

Q8: Is this product suitable for outdoor applications?

Yes. The hot-dipped galvanized coating (Z61-Z80) provides excellent corrosion protection, making it ideal for outdoor applications like roofing, fences, and construction. For harsh environments, higher coating weights are recommended.

Q9: Can you customize the width and coil weight?

Yes, we offer customized width, length, and coil weight based on your requirements. Please contact our sales team with your specifications.
