Inconel 600 601 625 718 800 Wire Resistance Heating Alloy Steel Wire Rod Nickel

Basic Information
Place of Origin: Jiangsu,China
Brand Name: Ansteel Baostell, Wusteel
Certification: ISO9001/CE/SGS
Model Number: inconel 600 601 625 718 800
Minimum Order Quantity: 10TON
Delivery Time: 5-8weeks
Payment Terms: 30%T/T for deposit, 70% balance before shipment or L/C at sight
Supply Ability: 1000 Tons per month
Detail Information
Name: Hot Rolled Astm Aisi Monel 400 Monel 500 Alloy Steel Wire Rod Type: Alloy Steel Wire Rod
Grade: Monel/Inconel/Hastelloy/Nickel Alloy Standard: ASTM/JIS/DIN/GB
Wire Gauge: 0.1-15mm Surface Treatment: Bright,Pickled,Hydrogen Annealing
Technique: Cold Drawn
High Light:

inconel 600 spring wire


inconel 601 welding wire


incoloy 800 wire

Product Description

inconel 600 601 625 718 800 Wire Resistance Heating Alloy Steel Wire Rod Nickel

It is face-centered cubic lattice structure for use at temperature up to 1425°C (2600°F).The Nickel-Chromium alloy is characterized by good corrosion resistance in the reduction condition,alkaline solution,inorganic acid and good resistance to oxidation at high temperatures.

Chemical Content(%)

Alloy % Ni Cr Fe C Mn Si Cu P S
Min. 72 14 6
Max.   17 10 0.15 1 0.5 0.5 0.015 0.015

Mechanical Properties

Aolly status Tensile strength
Rm N/mm²
Yield strength
R P 0.2N/mm²
A 5 %
Brinell hardness
Melting Point
550 240 30 ≤195 8.4 1370-1425
500 180 35 ≤185 8.4 1370-1425

Good corrosion resistance to the reduction, oxidation, Nitric and other media,good stress corrosion cracking resistance,good corrosion resistance of the dry chlorine and chlorine hydride,good mechanical property when below zero, room temperature and high temperature,good anti-creep rupture strength.

It widely used in following field:

  1. Furnace components:heat treatment furnace flask and components.
  2. Chemical processing:vinyl chloride monomer production,oxide shaft chloride converted to six fluoride,corrosive alkali metal produce and usage filed,use hlorine produce titanium dioxide,organic or inorganic chlorine produce.
  3. Food processing.
  4. Petrochemical works production of catalytic regeneration.


Round Wire 0.03mm~10mm
Flat Wire(Ribbon) thickness 0.1mm~1.0mm,width 0.5mm~5.0mm
Strip thickness 0.2mm~3.0mm,width 0.5mm~200mm
Pipe OD:0.2mm~120mm,Wall:0.05~70mm L:5mm~6000mm

5.Grade Contrast

ASTM(American Society for Testing and Materials) UNS N06600
DIN(Deutsche Industrie Normen) W.Nr.2.4816,NiCrl 5Fe
BS(British Standards) NA14

6.Products and services
1). Pass: ISO9001 certification, and SO14001cetification;
2). Fine after-sale services;
3). Small order accepted;
4). Fast delivery.
